Compact Kitchen Layouts That Work in Small Flats

Start With the Tape Measure, Not the Catalogue

Small flats are full of awkward corners, chimney breasts, boxed-in pipework and windows that end exactly where you wanted a wall unit. Before you fall for a glossy showroom display, spend an evening measuring. Note the position of every door, socket, radiator, waste pipe and boiler. Record ceiling height too, because going up the wall is often the only direction left in a compact kitchen.

As a rough guide, you need at least 1 metre of clear floor space in front of any run of units so two people can pass without performing a polite shuffle. A worktop depth of 600mm is standard, but in tight spots a 500mm-deep run can buy you valuable circulation room without sacrificing much prep space. Draw the room on graph paper at a scale of 1:20, then cut out paper templates for the sink, hob, fridge and oven. Moving squares about on paper is far cheaper than moving cabinets.

Galley Kitchens: The Workhorse of Small Flats

The galley layout is the classic solution for narrow rooms, and for good reason. Two parallel runs give you the golden triangle of sink, hob and fridge within a couple of steps, so you never walk far to drain pasta or fetch butter. Aim for a 1.2m to 1.5m gap between the runs where you can. Anything narrower than 1 metre starts to feel like cooking in a corridor.

• Vary the depths. A full 600mm run on one side and a shallower 350mm to 400mm run on the other keeps the walkway generous while still giving you somewhere to store tins and spices.
• Keep the sink and hob on the same run if possible, leaving the opposite wall for tall units, a slim dishwasher and a full-height larder.
• Use the end of the run. A pull-out chopping board or a narrow wine rack can turn dead space next to a wall into something genuinely useful.

One trade-off to accept: galley kitchens rarely offer much room for a dining table. If you need seating, plan for a fold-down ledge or a pair of stackable stools tucked under an overhang rather than a fixed island.

L-Shape Layouts: Making the Corner Earn Its Keep

An L-shape works beautifully in a square-ish room and gives you two generous runs of worktop that meet in a corner. The catch is that corner itself. A standard 1000mm base unit in a corner wastes a huge amount of space, so think carefully about how you'll reach the back of it.

• Carousel or pull-out corner units are worth the extra cost in a small kitchen; a magic corner pull-out can hold a surprising amount of pans and dry goods.
• Place the sink in the corner of the L if you have a corner sink that angles across it, freeing the two legs of the run for prep and appliances.
• Leave 400mm to 600mm of worktop on either side of the hob for landing hot pans and chopping vegetables.
• Finish the short leg with a tall unit rather than a base unit if you're short on storage; a 2.1m-high larder goes a long way in a flat.

The L-shape also tends to leave one wall free for a slim table, a rack of hooks or a small dresser, which helps a compact kitchen feel less like a service area.

Peninsula Designs: An Island When There Isn't Room for One

If a freestanding island would block your walkway, a peninsula attached to one run of units gives you the same social feel without the squeeze. It creates a natural division between cooking and living zones, which matters hugely in open-plan flats where the sofa sits metres from the hob.

Keep the peninsula between 900mm and 1.1m deep, with an overhang of 300mm if you want stools underneath. That overhang gives knees somewhere to go and stops the whole thing feeling like a bench at a bus stop. Use the peninsula for the sink and dishwasher on one side, then have the seating side plain so people aren't staring at a control panel while they eat breakfast.

Watch out for clearance. You need at least 900mm between the peninsula and any wall or opposite run, and closer to 1.1m if people will be sitting there while someone else cooks. Draw the seating chairs in position on your plan, not just the cabinetry.

Vertical Storage and Clever Detail

When floor space is scarce, the walls and the ceiling become your best friends. Run wall units to the ceiling rather than stopping with a dusty gap above them, and choose a handleless style so doors don't knock into each other in tight corners.

• Use the full height with a tall larder for the fridge, oven and dry goods stacked in one column. This frees up the rest of the run for worktop.
• Fit a rail or hanging system on splashback areas for utensils, mugs and pans, keeping worktops clear for actual chopping.
• Choose a slimline or integrated dishwasher and consider a 450mm appliance rather than the standard 600mm if you live alone or as a couple.
• Add drawers instead of cupboards below the worktop where you can; deep pan drawers hold more than a base unit with a single shelf and are far easier to use.
• Think about lighting with under-cabinet LED strips, so you're not working in your own shadow on a dark winter evening.

Finally, be honest about how you cook. If you mostly use a microwave and a kettle, don't sacrifice worktop for a full range cooker. If you batch-cook every Sunday, invest in a proper extractor and a hob with room around it. A compact kitchen that matches your habits will always outperform a beautiful one that fights them.
